LCD: 17" TFT LCD
Resolution: Up to 1280 x 1024
Active Area: 377.920 (H) x 270.336 (V)
Pixel Pitch: 0.264 (H) x 0.264 (V)
Pixel Arrangement: RGB Vertical Stripe
Viewing Angle: 80/80/80/80 degree (U/D/L/R)
Contrast Ratio: 1000 : 1
Response Time: 3.5 ms (Raising)/1.5 ms (Falling)
Brightness: 250 cd/m2
Touch Type: Resistive touch for TM-7117E, IR touch for TM-7117E-IR
Interface: USB
